WR-28 Coaxial Rectangular Horn Antenna

For the male version please CLICK HERE to contact us.

This model may be purchased with optional antenna testing services.
A gain measurement test is offered under service number FTA-0400GAIN-AA.
A 2D pattern measurement test is offered under service number FTA-0400PATT-AA.

CLICK HERE to read more about our antenna measurement capabilities.

SAR-1725-28KF-E2-WR is a Ka-band pyramidal horn antenna with a end launch (180°) WR-28 waveguide to 2.92 mm (F) coax panel mount adapters to cover the frequency range of 26.5 GHz to 40 GHz. The antenna offers 17 dBi nominal gain and a typical half power beamwidth of 23 degrees on the E-plane and 24 degrees on the H-plane. The antenna supports linear polarized waveforms. The model with 2.92 mm (M) coax panel mount adapter is offered under model number SAR-1725-28KM-E2-WR.
