Ka-Band Scalar Feed Horn Antenna

17 dBi Gain, 33 to 38.5 GHz, 0.250" Diameter Circular Waveguide
SKU:SAF-3333931725-250-S1
Availability:IN STOCKPlease contact us if you need more units than what is available online.
SAF-3333931725-250-S1 is a Ka-band scalar feed horn antenna that operates from 33 to 38.5 GHz. The antenna offers a 17 dB nominal gain, 25 degree typical half power beamwidth, and -28.5 dB typical sidelobe level. The scalar feed horn is equipped with a 0.250" diameter circular waveguide that supports both linear and circular polarization. A rectangular waveguide port configuration that only supports linear polarization is available under a different model number.
ECCN: EAR99
Login to View Pricing

Bulk Pricing

QuantityPrice
1 - 4$1,650.00
5 - 9$1,485.00
10 - 24$1,336.50

Bulk Pricing

Login to View Pricing

Technical Details

Minimum Frequency33 GHz
Maximum Frequency38.5 GHz
Gain17 dBi
3 dB Beamwidth, E-plane25°
3 dB Beamwidth, H-plane25°
Return Loss20 dB
PolarizationLinear and Circular
Antenna Port0.250" Dia Circular WG
