Ka-Band Scalar Feed Horn Antenna

17 dBi Gain, 24 to 42 GHz, 0.328" Diameter Circular Waveguide
SKU:SAF-2434231725-328-S1
Availability:IN STOCKPlease contact us if you need more units than what is available online.
SAF-2434231725-328-S1 is a Ka-band scalar feed horn antenna that covers several popular 5G bands in the frequency range of 24 to 42 GHz. The horn antenna offers a nominal gain of 17 dBi, typical half power beamwidth of 25 degrees and side lobe levels of -25 dB or lower. The antenna port is a 0.328” diameter circular waveguide with a UG-599/U-M flange that supports both linear and circular polarized waveforms. A rectangular waveguide port configuration that only supports linear polarization is available under a different model number. The dual polarized configuration with orthomode transducer integrated is available under the model SAF-2434231725-328-S1-280-DP.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency24 GHz
Maximum Frequency42 GHz
Gain17 dBi
3 dB Beamwidth, E-plane25°
3 dB Beamwidth, H-plane25°
Return Loss15 dB
PolarizationLinear and Circular
Antenna Port0.328" Dia Circular WG
