Dielectric Resonator Oscillator

16 GHz, ±150 MHz Tuning Range, +13 dBm Output Power, SMA (F)
SOD-16303213-SF-S4 is a mechanically tuned, dielectric resonator oscillator with a center frequency of 16 GHz and a mechanical tuning range of ±150 MHz. The oscillator delivers a nominal output power of +13 dBm with a low phase noise and harmonic emissions. The oscillator takes a +12 VDC/150 mA DC bias. The RF output is equipped with a female SMA connector.
Login to view pricing

Bulk Pricing

Quantity Price
1 - 4 $1,500.00
5 - 9 $1,350.00
10 - 24 $1,215.00

Bulk Availability


Bulk Pricing

Login to view pricing

Technical Details

Center Frequency16 GHz
Output Power+13 dBm
Mechanical Tuning Range±150 MHz
Phase Noise-80 dBc/Hz @ 100 KHz Offset
Spurious-75 dBc
Harmonics-20 dBc
Bias+12 VDC/150 mA
RF PortSMA (F)
