WR-12 Waveguide Scalar Feed Horn Antenna

This model may be purchased with optional antenna testing services.
A gain measurement test is offered under service number FTA-WR12GAIN-AA.
A 2D pattern measurement test is offered under service number FTA-WR12PATT-AA.

CLICK HERE to read more about our antenna measurement capabilities.

SAF-7138631630-12-S1 is an E-band scalar feed horn antenna that operates from 71 to 86 GHz. The antenna offers a 16 dBi nominal gain, 30 degree typical half power beamwidth, and -25 dB typical sidelobe levels. The scalar feed horn is equipped with a WR-12 rectangular waveguide that supports vertical linear polarization. Circular waveguide ports supporting both linear and circular polarization are available under a different model number.
