Dielectric Resonator Oscillator

15 GHz, ±5 MHz Tuning Range, +13 dBm Output Power, SMA (F)
SKU:SOD-15301113-SF-S4
Availability:Contact Us for Quote
SOD-15301113-SF-S4 is a mechanically tuned, dielectric resonator oscillator with a center frequency of 15 GHz and a mechanical tuning range of ±5 MHz. The oscillator delivers a nominal output power of +13 dBm with a low phase noise and harmonic emissions. The oscillator takes a +12 VDC/100 mA DC bias. The RF output is equipped with a female SMA connector.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Center Frequency15 GHz
Output Power+13 dBm
Mechanical Tuning Range±5 MHz
Phase Noise-90 dBc/Hz @ 100 KHz Offset
Spurious-75 dBc
Harmonics-20 dBc
Bias+12 VDC/100 mA
RF PortSMA (F)
