WR-42 Waveguide Pyramidal Horn Antenna

15 dBi Gain, 18 to 26.5 GHz, K-Band
SKU:SAR-1532-42-S2
Availability:IN STOCKPlease contact us if you need more units than what is available online.
SAR-1532-42-S2 is a K-band pyramidal horn antenna that operates from 18.0 GHz to 26.5 GHz. The antenna offers 15 dBi nominal gain and a typical half power beamwidth of 32 degrees on the both the E-plane and H-plane. The antenna supports linear polarized waveforms. The input of this antenna is a WR-42 waveguide with UG-595/U flange. Other antennas with different gain and antenna ports are offered under different model numbers.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency18 GHz
Maximum Frequency26.5 GHz
Gain15 dBi
3 dB Beamwidth, E-Plane32°
3 dB Beamwidth, H-Plane32°
Return Loss15 dB
Antenna PortWR-42 Waveguide
