Ka-Band Scalar Feed Horn Antenna

15 dBi Gain, 22 to 44 GHz, 0.328" Diameter Circular Waveguide
Availability:IN STOCKPlease contact us if you need more units than what is available online.
This model may be purchased with optional antenna testing services.
A gain measurement test is offered under service number FTA-0500GAIN-AA.
A 2D pattern measurement test is offered under service number FTA-0500PATT-AA.

CLICK HERE to read more about our antenna measurement capabilities.

SAF-2234431535-328-S1 is a Ka-band scalar feed horn antenna that operates from 22 to 44 GHz. The antenna offers a 15 dBi nominal gain, 35 degree typical half power beamwidth. The nominal side lobe levels are -25 dB or lower. The scalar feed horn is equipped with a Ø 0.328" circular waveguide with UG-599/U compatible flange that supports both linear and circular polarized waveforms. A rectangular waveguide port configuration that only supports linear polarization is available under a different model number.
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency22 GHz
Maximum Frequency44 GHz
Gain15 dBi
3 dB Beamwidth, E-plane35°
3 dB Beamwidth, H-plane35°
Return Loss10 dB
PolarizationLinear and Circular
Antenna Port0.328" Dia Circular WG
