K-Band Scalar Feed Horn Antenna

15 dBi Gain, 18 to 26.5 GHz, 0.470" Diameter Circular Waveguide
SKU:SAF-1832731535-470-S1
Availability:IN STOCKPlease contact us if you need more units than what is available online.
SAF-1832731535-470-S1 is a K-band scalar feed horn antenna that operates from 18 to 26.5 GHz. The antenna offers a 15 dBi nominal gain, 35 degree typical half power beamwidth. The nominal sidelobe levels are -25 dB or lower. The scalar feed horn is equipped with a 0.470” diameter circular waveguide with UG-595/U compatible flange that supports both linear and circular polarized waveforms. A rectangular waveguide port configuration that only supports linear polarization is available under a different model number.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Quantity Price
1 - 4 $1,900.00
5 - 9 $1,710.00
10 - 24 $1,539.00

Bulk Availability

QuantityAvailability

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency18 GHz
Maximum Frequency26.5 GHz
Gain15 dBi
3 dB Beamwidth, E-plane35°
3 dB Beamwidth, H-plane35°
Return Loss15 dB
PolarizationLinear and Circular
Antenna Port0.470" Dia Circular WG
