D-Band Scalar Feed Horn Antenna

15 dBi Gain, 110 to 170 GHz, 0.082" Diameter Circular Waveguide
SKU:SAF-1141741535-082-S1
Availability:4 to 6 Weeks ARO
SAF-1141741535-082-S1 is a D-band scalar feed horn antenna that operates from 110 to 170 GHz. The antenna offers a 15 dBi nominal gain, 35 degree typical half power beamwidth, and -25 dB typical side lobe level. The scalar feed horn is equipped with a 0.082" diameter circular waveguide that supports both linear and circular polarization. A rectangular waveguide port configuration that only supports linear polarization is available under a different model number.
ECCN: EAR99
To view pricing or check order status

Bulk Pricing

QuantityPrice
1 - 2$2,700.00
3 - 4$2,565.00
5 +$2,436.75

Bulk Pricing

Sign In / Create An Account to view pricing

Technical Details

Minimum Frequency110 GHz
Maximum Frequency170 GHz
Gain15 dBi
3 dB Beamwidth, E-plane35°
3 dB Beamwidth, H-plane35°
Return Loss20 dB
PolarizationLinear and Circular
Antenna Port0.082" Dia Circular WG
