W-Band Scalar Feed Horn Antenna

13 dBi Gain, 75 to 110 GHz, 0.110" Diameter Circular Waveguide
SKU:SAF-7531141340-110-S1
SAF-7531141340-110-S1 is a W-band scalar feed horn antenna that operates from 75 to 110 GHz. The antenna offers a 13 dBi nominal gain, 40 degree typical half power beamwidth, and -25 dB typical side lobe level. The scalar feed horn is equipped with a 0.110” diameter circular waveguide that supports both linear and circular polarization. A rectangular waveguide port configuration that only supports linear polarization is available under a different model number.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency75 GHz
Maximum Frequency110 GHz
Gain13 dBi
3 dB Beamwidth, E-plane40°
3 dB Beamwidth, H-plane40°
Return Loss20 dB
PolarizationLinear and Circular
Antenna Port0.110" Dia Circular WG
