E-Band Scalar Feed Horn Antenna, Limited Run

This is a Limited Run model, so inventory may not be restocked. Customers who anticipate long-term requirements should consider SAF-6039031340-141-S1 as an alternative solution. Read more about Limited Run Products here.

SAF-6039031340-141-S1-2 is a WR-12 scalar feed horn antenna that covers the frequency range of 60 to 90 GHz. At center frequency, the horn antenna exhibits 13 dBi nominal gain and a typical half power beamwidth of 40 degrees. The antenna has a return loss of 20 dB, and -25 dB side lobes on the E-Plane and H-Plane. The antenna is equipped with a Ø 0.141” circular waveguide with a UG-387/U-M flange.
