WR-90 Waveguide Rectangular Horn Antenna

This model may be purchased with optional antenna testing services.
A gain measurement test is offered under service number FTA-0400GAIN-AA.
A 2D pattern measurement test is offered under service number FTA-0400PATT-AA.

CLICK HERE to read more about our antenna measurement capabilities.

SAR-1248-90-S3 is a X-band pyramidal horn antenna that operates from 8.2 GHz to 12.4 GHz. The antenna offers 12 dBi nominal gain and a typical half power beamwidth of 52 degrees on the E-plane and 42 degrees on the H-plane. The antenna supports linear polarized waveforms. The input of this antenna is a WR-90 waveguide with UG-39/U flange.
