4-Port Bi-directional Directional Coupler

110 to 170 GHz, 6 dB Coupling, 40 dB Directivity, WR-06 Waveguide, D-Band
SKU:SWD-0640H-06-BB
Availability:IN STOCKPlease contact us if you need more units than what is available online.
SWD-0640H-06-BB is a D band, four-port waveguide bi-directional coupler that delivers a 6 dB nominal coupling level and 40 dB nominal directivity across the full waveguide band from 110 to 170 GHz. The three-port coupler uses a traditional multi-hole and split block design to achieve a flat coupling level, high directivity, and low insertion loss. The interfaces of the coupler are WR-06 waveguides with UG-387/U-M anti-cocking flanges. Custom coupling levels are available under different model numbers.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Quantity Price
1 - 4 $1,700.00
5 - 9 $1,530.00
10 - 24 $1,377.00

Bulk Availability

QuantityAvailability

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency110 GHz
Maximum Frequency170 GHz
Insertion Loss3 dB
Coupling6 dB
Directivity40 dB
Return Loss20 dB
Coupler Type4-Port Bi-directional, Split-block
RF PortsWR-06 WG
