D-Band Positive Amplitude Detector

SFD-114174-243-06SF-P1 is a D Band amplitude detector that can be used for full or narrow band applications. The detector is zero biased and intended for small signal detection purposes. With a distinct circuitry design and careful diode selection, the detector exhibits high sensitivity and extremely flat output characteristics across the full waveguide operating bandwidth. The detector is designed to have a 24 GHz video bandwidth and a 1 MΩ video output impedance. The minimum detectable signal level is approximately -50 dBm.
