D-Band Faraday Isolator

110 to 170 GHz, 30 dB Isolation, 3 dB Insertion Loss, WR-06 Waveguide
SKU:STF-06-S1
Availability:IN STOCKPlease contact us if you need more units than what is available online.
STF-06-S1 is a full band Faraday isolator that operates from 110 to 170 GHz. The Faraday isolator is constructed with a longitudinal, magnetized ferrite rod that causes a Faraday rotation of the incoming RF signal. The Faraday isolator offers 30 dB typical isolation and 3 dB nominal insertion loss with good flatness. The input and output ports are WR-06 waveguides with UG-387/U-M flanges.
ECCN: EAR99
Login to View Pricing

Bulk Pricing

Quantity Price
1 - 4 $1,850.00
5 - 9 $1,665.00
10 - 24 $1,498.50

Bulk Availability

QuantityAvailability

Bulk Pricing

Login to View Pricing

Technical Details

Minimum Frequency110 GHz
Maximum Frequency170 GHz
Insertion Loss3 dB
Isolation30 dB
VSWR1.4
Power Handling0.8 W
RF PortWR-06 Waveguide
