D-Band Compact Phase Shifter

110 to 170 GHz, 0 to 180° Range, WR-06 Waveguide
SKU:STP-18-06-M1-C-1.2
STP-18-06-M1-C-1.2 is a WR-06 compact micrometer driven phase shifter that covers the frequency range from 110 to 170 GHz. The phase shifter features a high resolution precision micrometer which allows for finer adjustment sensitivity than a standard micrometer. The phase shifter is an ideal piece of equipment in waveguide systems where broadband phase shifting is required. The phase shifter exhibits a 1.2 dB typical insertion loss and an adjustable phase range of up to 180 degrees.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Quantity Price
1 - 4 $1,400.00
5 - 9 $1,260.00
10 - 24 $1,134.00

Bulk Availability

QuantityAvailability

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency110 GHz
Maximum Frequency170 GHz
Insertion Loss1.2 dB
Phase Shifting Range0 to 180°
Power Handling100 mW (CW)
Input/OutputWR-06 Waveguide
