SMA Coaxial Bandpass Filter

11.6 to 13.1 GHz, 50 dB Rejection
Availability:IN STOCKPlease contact us if you need more units than what is available online.
SCF-12315250-SFSF-B3 is a coaxial bandpass filter with a passband frequency of 11.6 to 13.1 GHz. The typical insertion loss of the bandpass filter is 0.8 dB and the passband ripple is ±0.3 dB. The rejection frequencies are 10.6 GHz or less and 14 GHz or higher. The typical rejection is 50 dB and the typical passband return loss of the filter is 18 dB. The RF connectors of the the filter are SMA Female connectors. Other configurations are available under different model numbers.
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Minimum Passband Frequency11.6 GHz
Maximum Passband Frequency13.1 GHz
Low Side Rejection50 dB
High Side Rejection70 dB
Return Loss18 dB
Insertion Loss0.8 dB
Impedance50 Ohms
RF PortsSMA (F)
