90 Degree Coaxial Hybrid Coupler

SCZ-1032731009-KFKF-43 is a coaxial 90-degree hybrid coupler that covers the frequency range of 10 to 26.5 GHz. The nominal coupling is 3 dB and the typical insertion loss is 2.6 dB. The typical isolation of the coupler is 10 dB. The RF connectors of the coupler are female 2.92 mm (K) connectors. The power handling of the coupler is 50 watts maximum. Other configurations, such as different connectors for input and output, are available under different model numbers.
