Dielectric Resonator Oscillator

10 GHz, ±10 MHz Tuning Range, +14 dBm Output Power, SMA (F)
SKU:SOD-10302114-SF-S4
Availability:Contact Us for Quote
SOD-10302114-SF-S4 is a mechanically tuned, dielectric resonator oscillator with a center frequency of 10 GHz and a mechanical tuning range of ±100 MHz. The oscillator delivers a nominal output power of +14 dBm with a low phase noise and harmonic emissions. The oscillator takes a +8 VDC/50 mA DC bias. The RF output is equipped with a female SMA connector.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Center Frequency10 GHz
Output Power+14 dBm
Mechanical Tuning Range±100 MHz
Phase Noise-100 dBc/Hz @ 100 KHz Offset
Spurious-75 dBc
Harmonics-20 dBc
Bias+8 VDC/50 mA
RF PortSMA (F)
