WR-12 Waveguide Rectangular Horn Antenna

10 dBi Gain, 60 to 90 GHz, E-Band
SKU:SAR-1055-12-S2
Availability:IN STOCKPlease contact us if you need more units than what is available online.
SAR-1055-12-S2 is an E-band rectangular horn antenna that operates from 60 GHz to 90 GHz. The antenna offers 10 dBi nominal gain and a typical half power beamwidth of 55 degrees on both E-plane and H-plane, respectively. The antenna supports linear polarized waveforms. The input of this antenna is a WR-12 waveguide with UG-387/U flange.
ECCN: EAR99
To view pricing or check order status

Bulk Pricing

QuantityPrice
1 - 24$490.00
25 - 49$441.00
50 +$396.90

Bulk Pricing

Sign In / Create An Account to view pricing

Technical Details

Minimum Frequency60 GHz
Maximum Frequency90 GHz
Gain10 dBi
3 dB Beamwidth, E-Plane55°
3 dB Beamwidth, H-Plane55°
Return Loss20 dB
Antenna PortWR-12 Waveguide
