G-Band Choke Flange Feed Horn Antenna

10 dBi Gain, 0.059" Diameter Circular Waveguide
Availability:IN STOCKPlease contact us if you need more units than what is available online.
SAH-1442241060-059-S1 is a G-band choke flange feed horn antenna that operates from 140 to 220 GHz. The antenna offers a nominal gain of 10 dBi, typical half power beamwidth in E and H plane of 60 degrees and typical side lobe levels of -30 dB for both E and H plane. The antenna port is a 0.059” circular waveguide with a UG-387/U-M anti-cocking flange that supports linear and circular polarization.
Login to view pricing

Bulk Pricing

Quantity Price
1 - 4 $2,000.00
5 - 9 $1,800.00
10 - 24 $1,620.00

Bulk Availability


Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency140 GHz
Maximum Frequency220 GHz
Gain10 dBi
3 dB Beamwidth, E-Plane60°
3 dB Beamwidth, H-Plane60°
Return Loss20 dB
Antenna Port0.059" Diameter Circular Waveguide
