Coaxial Directional Coupler

10 dB Coupling, 18 to 50 GHz, 2.4 mm (F), 50 Watts
Availability:6 to 8 Weeks ARO
SCD-1835031010-2F-SA is a 10 dB coaxial directional coupler that covers the frequency range of 18 to 50 GHz. The nominal insertion loss of the coupler is 2.2 dB and the coupling ripple is ±1.2 dB. The directivity of the coupler is 10 dB. The RF connectors of the coupler are 2.4 mm female connectors. The power handling of the coupler is 50 watts maximum. Other configurations, such as different connectors for input and output, are available under different model numbers.
Login to View Pricing

Bulk Pricing

1 - 4$2,150.00
5 - 9$1,935.00
10 - 24$1,741.50

Bulk Pricing

Login to View Pricing

Technical Details

Minimum Frequency18 GHz
Maximum Frequency50 GHz
Insertion Loss2.2 dB
Coupling10 dB
Power Handling50 Watts
Directivity10 dB
Port Return Loss10 dB
Impedance50 Ohms
RF Ports2.4 mm Female
