Coaxial Directional Coupler

10 dB Coupling, 18 to 40 GHz, 2.92 mm (F), 20 Watts
SKU:SCD-1834031012-KF-SA
Availability:Contact Us for Quote
SCD-1834031012-KF-SA is a 10 dB coaxial directional coupler that covers the frequency range of 18 to 40 GHz. The nominal insertion loss of the coupler is 1.5 dB and the coupling ripple is ± 1.0 dB. The directivity of the coupler is 12 dB. The RF connectors of the coupler are 2.92 mm (K) female connectors. The power handling of the coupler is 20 watts maximum. Other configurations, such as different connectors for input and output, are available under different model numbers.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency18 GHz
Maximum Frequency40 GHz
Insertion Loss1.5 dB
Coupling10 dB
Power Handling20 Watts
Directivity12 dB
Port Return Loss14 dB
Impedance50 Ohms
RF Port2.92 mm Female
