Dielectric Resonator Oscillator

10.2 GHz, ±100 MHz Tuning Range, +17 dBm Output Power, SMA (F)
SKU:SOD-10302217-SF-S2-3
Availability:8 to 10 Weeks ARO
SOD-10302217-SF-S2-3 is a mechanically tuned, dielectric resonator oscillator with a center frequency of 10.2 GHz and a mechanical tuning range of ±100 MHz. The oscillator delivers a nominal output power of +17 dBm with a low phase noise and harmonic emissions. The oscillator takes a +12 VDC/70 mA DC bias. The RF output is equipped with a female SMA connector.
ECCN: EAR99
To view pricing or check order status

Bulk Pricing

QuantityPrice
1 - 4$1,500.00
5 - 9$1,350.00
10 +$1,215.00

Bulk Pricing

Sign In / Create An Account to view pricing

Technical Details

Center Frequency10.2 GHz
Output Power+17 dBm
Mechanical Tuning Range±100 MHz
Phase Noise-100 dBc/Hz @ 100 KHz Offset
Spurious-75 dBc
Harmonics-25 dBc
Bias+12 VDC/70 mA
RF PortSMA (F)
