2-Way Coaxial Power Splitter

1 to 40 GHz, 2.92 mm (F)
SKU:SCS-0134031215-KFKF-22
Availability:4 to 6 Weeks ARO
Model SCS-0134031215-KFKF-22 is a coaxial 2-way power splitter with a typical insertion loss of 1.2 dB at each output port and a typical isolation of 15 dB across the frequency range of 1 to 40 GHz. The power splitter has a maximum power handling of 20 W (CW) and a typical amplitude unbalance of 0.5 dB. The return loss for all ports is 11 dB typical. The RF connectors of the power splitter are female SMA connectors.
ECCN: EAR99
Login to View Pricing

Bulk Pricing

Quantity Price
1 - 4 $1,300.00
5 - 9 $1,170.00
10 - 24 $1,053.00

Bulk Availability

QuantityAvailability

Bulk Pricing

Login to View Pricing

Technical Details

Minimum Frequency1 GHz
Maximum Frequency40 GHz
Ways2
Insertion Loss1.2 dB
Port Isolation15 dB
Return Loss11 dB
Impedance50 Ohms
RF ConnectorsK (F)
