2-Way Coaxial Power Splitter

1 to 27 GHz, SMA (F)
SKU:SCS-0132732616-SFSF-22
Availability:4 to 6 Weeks ARO
SCS-0132732616-SFSF-22 is a coaxial 2-way power splitter with a typical insertion loss of 2.6 dB at each output port and a typical isolation of 16 dB across the frequency range of 1 to 27 GHz. The power splitter has a nominal power handling of 20 W (CW) and a typical amplitude unbalance of ±0.4 dB. The return loss for all ports is 12 dB typical. The RF connectors of the power splitter are female SMA connectors.
ECCN: EAR99
To view pricing or check order status

Bulk Pricing

QuantityPrice
1 - 9$550.00
10 - 24$495.00
25 +$445.50

Bulk Pricing

Sign In / Create An Account to view pricing

Technical Details

Minimum Frequency1 GHz
Maximum Frequency27 GHz
Ways2
Insertion Loss2.6 dB
Port Isolation16 dB
Return Loss12 dB
Impedance50 Ohms
RF ConnectorsSMA (F)
