Inner Coaxial DC Block

1.85 mm, 10 MHz to 67 GHz
SKU:SCB-016-VFVM-U2
Availability:IN STOCKPlease contact us if you need more units than what is available online.
SCB-016-VFVM-U2 is a coaxial DC block that prevents the flow of DC current in the frequency range of 10 MHz to 67 GHz. The DC block has a typical insertion loss of 1 dB, a nominal return loss of 15 dB, and a characteristic impedance of 50 ohms, respectively. It is manufactured with 1.85 mm male and female connectors for convenient circuit insertion. The breakdown voltage is +16 Volts.
ECCN: EAR99
Login to View Pricing

Bulk Pricing

Quantity Price
1 - 24 $465.00
25 - 49 $418.50
50 - 99 $376.65

Bulk Availability

QuantityAvailability
1 In Stock

Bulk Pricing

Login to View Pricing

Technical Details

Minimum Frequency10 MHz
Maximum Frequency67 GHz
Return Loss15 dB
Impedance50 Ohms
Insertion Loss1 dB
Connector 11.85 mm Female
Connector 21.85 mm Male
