Broadband Amplifier

0.01 to 70 GHz, 30 dB Gain, +15 dBm P1dB, 6.0 dB Noise Figure, 1.85 mm (F)
SKU:SBB-0117033015-VFVF-E3
Availability:IN STOCKPlease contact us if you need more units than what is available online.
SBB-0117033015-VFVF-E3 is a broadband amplifier with a typical small signal gain of 30 dB, a nominal P1dB of +15 dBm, and a typical noise figure of 6.0 dB across the frequency range of 0.01 to 70 GHz. The DC power requirement for the amplifier is +12 VDC/600 mA. The use of a heat sink is advised to assist in cooling the device. The RF connectors are female 1.85 mm connectors. Other port configurations are available under different model numbers.

Your application may require a heatsink. Visit our Heatsink Blog for assistance with choosing an appropriate heatsink for use with this model.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Quantity Price
1 $7,850.00
2 $7,457.50
3 - 4 $7,084.63

Bulk Availability

QuantityAvailability

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency0.01 GHz
Maximum Frequency70 GHz
Gain30 dB
P1dB+15 dBm
Psat+16 dBm
Input Return Loss10 dB
Output Return Loss10 dB
DC Bias+12 VDC/600 mA
RF Input/Output1.85 mm (F)
