Broadband Amplifier, Product Discontinued

0.01 to 50 GHz, 40 dB Gain, +18 dBm P1dB, 6.0 dB Noise Figure, 2.4 mm (F)
SKU:SBB-0115034019-2F2F-E3
Availability:Product Discontinued
Select up to 4 products to compare.
Select up to 4 products to compare.
This product has been improved and is now listed as SBB-0115034510-2F2F-E3 and SBB-0115033910-2F2F-E3. Read more about Limited Run Products here.



SBB-0115034019-2F2F-E3 is a broadband amplifier with a minimum small signal gain of 40 dB, a nominal P1dB of +18 dBm, and a typical noise figure of 6.0 dB across the frequency range of 0.01 to 50 GHz. The DC power requirement for the amplifier is +12 VDC/400 mA. The use of a heat sink is advised to assist in cooling the device. The RF connectors are female 2.4 mm connectors. Other port configurations are available under different model numbers.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency0.01 GHz
Maximum Frequency50 GHz
Gain40 dB
P1dB+18 dBm
Psat+20 dBm
Input Return Loss8 dB
Output Return Loss8 dB
DC Bias+12 VDC/400 mA
RF Input/Output2.4 mm (F)
