U-Band Low Noise Amplifier,

40 to 60 GHz, 45 dB Gain, 4.0 dB NF
SKU:SBL-4036034540-VFVF-S1
Availability:4 to 6 Weeks ARO
SBL-4036034540-VFVF-S1 is a low noise amplifier with a typical small signal gain of 45 dB across the frequency range of 40 to 60 GHz and a nominal noise figure of 4.0 dB. The DC power requirement for the amplifier is +8 VDC/250 mA. The input and output port configurations are both female 1.85 mm (V) connectors. Other port configurations, such as inline and right-angle waveguides, are also available under different model numbers.

Your application may require a heatsink. Visit our Heatsink Blog for assistance with choosing an appropriate heatsink for use with this model.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Quantity Price
1 - 2 $3,150.00
3 - 4 $2,992.50
5 - 9 $2,842.88

Bulk Availability

QuantityAvailability

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency40 GHz
Maximum Frequency60 GHz
Gain45 dB
Noise Figure4 dB
P1dB+16 dBm
Input Return Loss8 dB
Output Return Loss10 dB
DC Bias+8 VDC/250 mA
RF Input/Output1.85mm (F)
