Q-Band Low Noise Amplifier

33 to 50 GHz, 30 dB Gain, 4.0 dB Noise Figure, 2.4 mm (F)
SKU:SBL-3335033040-2F2F-S1
Availability:IN STOCKPlease contact us if you need more units than what is available online.
SBL-3335033040-2F2F-S1 is a low noise amplifier with a typical small signal gain of 30 dB and a nominal noise figure of 4.0 dB across the frequency range of 33 to 50 GHz. The DC power requirement for the amplifier is +8 VDC/330 mA. The input and output port configurations are both female 2.4 mm connectors. Other port configurations, such as male 2.4 mm connectors and WR-22 waveguides for either the input or output port, are also available under different model numbers.
ECCN: EAR99
To view pricing or check order status

Bulk Pricing

QuantityPrice
1 - 2$3,150.00
3 - 4$2,992.50
5 +$2,842.88

Bulk Pricing

Sign In / Create An Account to view pricing

Technical Details

Minimum Frequency33 GHz
Maximum Frequency50 GHz
Gain30 dB
Noise Figure4.0 dB
P1dB+12 dBm
Input Return Loss10 dB
Output Return Loss7 dB
DC Bias+8 VDC/330 mA
RF Input/Output2.4 mm (F)
