Broadband Low Noise Amplifier

20 to 50 GHz, 40 dB Gain, 3.5 dB Noise Figure, 2.4 mm (F)
SKU:SBL-2035034035-2F2F-S1
Availability:3 to 4 Weeks ARO
SBL-2035034035-2F2F-S1 is a low noise amplifier with a typical small signal gain of 40 dB and a nominal noise figure of 3.5 dB across the frequency range of 20 to 50 GHz. The DC power requirement for the amplifier is +6 VDC/800 mA. The input and output port configurations are both female 2.4 mm connectors. Other port configurations are available under different model numbers.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency20 GHz
Maximum Frequency50 GHz
Gain40 dB
Noise Figure3.5 dB
P1dB+22 dBm
Input Return Loss9 dB
Output Return Loss9 dB
DC Bias+8 VDC/800 mA
RF Input/Output2.4 mm (F)
