G-Band Low Noise Amplifier

140 to 220 GHz, 15 dB Gain, 7 dB Noise Figure, In-line WR-05 Waveguide
SKU:SBL-1442241570-0505-E1
Availability:1 to 2 Weeks ARO
Select up to 4 products to compare.
Select up to 4 products to compare.
SBL-1442241570-0505-E1 is a G-band low noise amplifier with a typical small signal gain of 15 dB and a nominal noise figure of 7.0 dB across the frequency range of 140 to 220 GHz. The DC power requirement for the amplifier is +8 VDC/50 mA. The input and output port configuration offers an inline structure with WR-05 waveguides and UG-387/U-M anti-cocking flanges.

Your application may require a heatsink. Visit our Heatsink Blog for assistance with choosing an appropriate heatsink for use with this model.
ECCN: 3A001.b.4
    Login to view pricing

    Bulk Pricing

    Login to view pricing

    Technical Details

    Minimum Frequency140 GHz
    Maximum Frequency220 GHz
    Gain15 dB
    Noise Figure7.0 dB
    P1dB-5 dBm
    Input Return Loss5 dB
    Output Return Loss5 dB
    DC Bias+8 VDC/60 mA
    RF Input/OutputWR-05 Waveguide
