Space

Our extensive standard offering can readily be updated for commercial space. Over the years, we have enabled clients working on technologies and applications like IoS, CubeSat, and low earth orbit (LEO) constellations.

Test Instrumentation

We're proud to partner with customers who are equipping the industry with test and measurement tools for millimeter-wave applications. From simple adapters to benchtop solutions, Eravant's products are designed and manufactured with instrumentation in mind.

Communications

With vast COTS and custom-designed product offerings, Eravant is prepared to help telecom equipment OEMs complete their millimeter-wave system configurations with minimum developmental costs and cycle times.

Radar

With vast COTS and custom-designed product offerings, Eravant is prepared to help telecom equipment OEMs complete their millimeter-wave system configurations with minimum developmental costs and cycle times.

Science & Academia

We serve scholars and scientists working on the cutting edge of their disciplines. From astrophysics to fusion technology, our engineers seek to understand clients' unique challenges so that our vast product knowledge can be used as a basis for their research needs.

5G & IOT

Our robust product offerings in Ka-Band and above have made us leaders in the 5G space for years. We were pioneers in hardware standardization. That vision has given our customers the advantage of time through rapid prototyping and reduced cycle times to market.

J Band Updates

This presentation introduces a selection of Eravant’s standard product offerings in the J-Band (220 to 330 GHz).

H Band Updates

This presentation introduces a selection of Eravant’s standard product offerings in the H-Band (170 to 260 GHz).

G Band Updates

This presentation introduces a selection of Eravant’s standard product offerings in the G-Band (140 to 220 GHz).

D Band Updates

This presentation introduces Eravant’s selective standard product offerings in the D- Band (110 to 170 GHz).

F Band Updates

This presentation introduces a selection of Eravant’s standard product offerings in the F-Band (90 to 140 GHz).

W Band Updates

This presentation introduces Eravant’s selective standard product offerings in the W-Band (75 to 110 GHz).

E Band Updates

This presentation introduces Eravant’s selective standard product offerings in the E-Band (60 to 90 GHz).

V Band Updates

This presentation introduces a selection of Eravant’s standard product offerings in the V-Band (50 to 75 GHz).

U Band Updates

This presentation introduces Eravant’s selective standard product offerings in the U-Band (40 to 60 GHz).

Q Band Updates

This presentation introduces a selection of Eravant’s standard product offerings in the Q-Band (33 to 50 GHz).

Ka Band Updates

This presentation introduces Eravant’s selective standard product offerings in the Ka-Band (26.5 to 40 GHz).

K Band Updates

This presentation introduces Eravant’s selective standard product offerings in the K-Band (18 to 26.5 GHz).

Hermetic Sealing

Eravant offers hermetically sealed versions of its Commercial Off-The-Shelf (COTS) active products by utilizing an in-house laser sealing system designed for hermetic sealing electronic packaging. Products are hermetically sealed via laser lidding using a glovebox QCW fiber laser welder. To verify seal integrity and quality, sealed packages are pressurized in a helium bombing chamber and leak tested with a helium mass spectrometer in accordance with MIL-STD-883E.

Company Presentation

We are an AS9100D certified, ITAR-registered, women-owned small business designing and manufacturing in the United States. Our mission is to make millimeter wave and sub-THz accessible by lowering budget, knowledge, and experience barriers so more engineers and scientists can work to realize the technology of the future.

Working With Eravant

Equipped with amenities like an ISO 8 Cleanroom, two anechoic test chambers, and a high-performance lab, the space is dedicated to our mission of enabling future technology.

Terahertz Products

Eravant THz components cover the frequency range of 100 to 300 GHz and include antennas, antenna accessories, low noise amplifiers, power amplifiers, mixers, frequency multipliers, and many other waveguide components.

Introducing Our Four Business Units

From its rich COTS component foundation, Eravant has developed a wide variety of standalone test equipment and partnered with key industry leaders to offer cost-effective test solutions for covering mmWave and sub-THz frequency bands up to 330 GHz.

Antenna Measurement Services

Eravant offers a range of standard antenna measurement services including gain, 2D, and 3D patterns. Frequency step size, operating bandwidth, and polarization settings can be specified by request.

LN2 Noise Source Calibration

Eravant waveguide noise sources are calibrated in-house using a cold reference termination that is cooled with liquid nitrogen. Eravant offers calibration services for waveguide banded noise sources up to 220 GHz and recommends repeating calibrations annually.

Near Field Range Testing

Eravant is one of the very few millimeter wave antenna manufacturing companies in the United States that can design, manufacture, and test large aperture microwave and millimeter wave antennas up to 110 GHz. In particular, Eravant has experience in production testing of large aperture Cassegain reflector antennas up to 2.4 m in diameter for Q/V-Band LEO/ GEO ground station applications.

Noise Figure Testing

Eravant offers precise and reliable noise figure testing services for amplifier components, employing the Y-factor method as the most common approach. This method uses a calibrated noise source that switches on and off to characterize the noise figure accurately.

Phase Noise Measurement Services

Eravant offers industry-leading phase noise testing services, utilizing real-time cross-correlation measurements for exceptional accuracy. Through a partnership with Holzworth, we have developed in-house test capabilities for precise phase noise measurement and actual noise floor measurement.

Power Measurement Services

Eravant offers precision power level measurement services spanning from DC to the sub-THz range, up to 500 GHz. Utilizing advanced diode detector power sensors, we cover a wide dynamic range (-70 to +20 dBm) with exceptional confidence and accuracy. For sub-THz measurements, our calorimetric power sensors also provide accurate and reliable results.

S-Parameter Measurement Services

Eravant provides comprehensive S-Parameter testing services for both coaxial and waveguide systems. For coaxial systems, we offer testing from 0.01 to 110 GHz in a single sweep, and for waveguide systems, we cover 18 to 325 GHz, offering full-band single-sweep testing across various frequency ranges.

Thermal Vacuum (TVAC) Component Testing

Eravant offers thermal vacuum test services with a recently acquired Ideal Vacuum ExploraVAC MAX Thermal Vacuum Test Chamber System. The chamber can simulate the extreme temperature ranges and vacuum conditions required for component testing for space qualification.

Space Heritage

Eravant has delivered more than 50,000 components and hardware for commercial, military, and space applications since its inception. The presentation shall review successful flight programs that incorporated Eravant hardware.

ACCESS STO Configuration Guide

The ACCESS line of VNA frequency extenders represents Eravant’s latest effort to make high-performance millimeter wave testing more attainable. Designed to deliver full-band coverage with a reduced footprint and lower price point, these models are part of our broader ACCESS portfolio—engineered to break cost and complexity barriers without compromising performance. The ACCESS extenders provide seamless integration into existing test setups while maintaining the reliability and precision Eravant is known for.

Contactless Waveguide Flange & mmW-Thz Test Setup Applications

Contactless Flange: which is a waveguide section with a novel flange design which forms RF choke when making connection to other waveguide flange to eliminate the requirements of perfect mechanical contact. Rail Setup: which is a rail structure to allow the millimeterwave VNA extenders to perform an easy alignment and connection of DUT and test equipment during the [S] parameter testing when Proxi-Flange™ is used.

Millimeter Wave VNA Extenders and Calibration Kits

Eravant offers high-performance and cost-effective VNA frequency extenders, drawing from an extensive range of broadband components and a history of subsystem design achievements. Eravant’s VNA Calibration Kits cover waveguide bands from 18 to 330 GHz.

One Millimeter (1 mm) Connectorized Components for Test & Instrumentation

What is 1 mm Connector? The 1 mm connector is a coax connector with coaxial line outer diameter 1.00 mm. The 1 mm connector supports the frequency range of DC to 110 GHz operation and can be stretched to cover DC to 130 GHz. There are many different types of connectors. For this presentation, only sparkplug and cable connectors are included.

STO Configuration Guide

Eravant’s VNA frequency extenders are used to increase the reach of coaxial Vector Network Analyzers to millimeter-wave and sub-THz frequencies. They are compatible with VNAs produced by major OEMs including Anritsu, Copper Mountain Technologies, Keysight, Rohde & Schwarz and others.

Uni-Guide™ Practical Waveguide Connector

The idea was from Eravant's own Product Development. There were too many product interface variations, product packages to manage, and excessive product development cycle time. It is used in the same way as the coaxial connector. It is field replaceable as long as glassbead is used and allows for various RF interfaces.

Waveguide Quick Connects

The idea was from Eravant’s own Testing Experience. Using waveguide screws to make the test set and DUT connections can cause scratches and marks on DUT surface. Two models are offered to cover operating frequency from 33 to 1 THz or beyond. We only need to use two thumb screws to make the waveguide connection easily reliable.

Dual Pol Antenna Applications for 5G

This presentation introduces Eravant's dual-pol antennas offering in broadband for 5G System Applications. Although the standard models are specified for full waveguide band operations, they can cover many Extended Millimeter Wave 5G Bands.

Eravant Main Catalog

Amplifier Catalog

Antenna Catalog

Sensor Catalog

ACCESS Synthesized Signal Generator

Eravant offers a series of portable, touchscreen and USB controlled synthesized signal generators under the ACCESS brand. They are designed to complement Eravant’s ACCESS series downconverter, frequency extender, and noise source modules for millimeterwave signal generation or frequency extension up to 330 GHz for various test equipment such as spectrum analyzers and noise figure analyzers.

ACCESS Radar Target Simulator

Eravant offers a series of doppler radar target simulators that operates in WR-42 to WR-10 waveguide banded frequencies. The target simulators utilizes a single-sideband-modulator to modulate the incoming signal transmitted by the radar under test and sends back either a higher or lower band signal through a circulator. Eravant also offers an ACCESS series function signal generator designed for use with the target simulators.

ACCESS mmWave VNA

For decades, engineers working above 50 GHz have faced the same compromise: bolt frequency extenders onto a general-purpose VNA and accept the cost, complexity, and fragility that come with it. Eravant and Copper Mountain Technologies set out to change that. The result is the mmWave VNA — a dedicated solution engineered specifically for millimeter-wave S-parameter characterization, anchored by Copper Mountain’s Model BFx-02 base VNA and paired with Eravant’s millimeter wave signal-chain expertise.

ACCESS mmWave Up Downconverter

A millimeter-wave communication link is built on two frequency translation stages that have to agree with each other: an upconverter that places the baseband or IF signal cleanly onto the radio-frequency carrier, and a downconverter that brings it back down. Eravant’s ACCESS mmWave Up/Downconverter family delivers both stages as matched, turnkey instruments. The STV upconverter takes the transmit IF and translates it on-band; the STC downconverter receives the RF and recovers the IF.

ACCESS mmWave Synthesizer

Millimeter-wave test benches, antenna ranges, and emerging 6G research setups all share one persistent need: a clean, programmable signal source that reaches deep into from 45 to 330 GHz seamlessly. Eravant’s ACCESS mmWave Source family answers that need by offering a portable, touchscreen-operated, low-phase noise signal source — turnkey, remote-programmable, and lab-grade across 45 GHz to 330 GHz from a single bench-friendly footprint.

ACCESS mmWave Noise Figure Test Set

Accurate noise figure measurement above 26.5 GHz demands more than a stand-alone noise meter or analyzer. Eravant brings everything together in one all-in-one solution — the compact down converter with embedded low-phase-noise synthesizer (STL-SG-022203-S1), and LN₂ calibrated noise source — pre-matched and factory calibrated as a turn-key Y-factor measurement chain that drops directly into any standard noise figure analyzer, making millimeter-wave noise figure testing more accessible, more convenient, and ready to use out of the box.

ACCESS VNA Frequency Extenders

Eravant offers a series of high performance, affordable vector network analyzer (VNA) frequency extenders under the ACCESS brand that enables frequency extension of 20 GHz coaxial VNAs up to 220 GHz. The ACCESS series VNA extenders utilize Eravant-proprietary technology to achieve high dynamic range and output power in a compact, lightweight package.

ACCESS Benchtop Frequency Extenders and Downconverters

Eravant offers a series of high performance, affordable benchtop frequency extender and downconverters under the ACCESS brand. The ACCESS series frequency extenders and downconverters offer a practical solution for extending the coverage of exisiting spectrum analyzers and signal generators to millimeterwave frequencies.

Waveguide Power Combiners

Eravant offers a series of waveguide power divider/combiners up to 330 GHz. These waveguide power dividers/combiners are used to merge or split multiple RF signals from power amplifiers while maintaining phase and power amplitude balance.

LN2 Noise Sources

Noise sources are widely used in Test & Measurement applications as stable reference signals for characterizing internally generated noise in components, receivers, and systems. They can also serve as broadband stimulus sources for built-in test functions in radar and communication systems, as well as for evaluating the linearity, stability, and dynamic behavior of high-power amplifiers.

Orthomode Transducers

Eravant offers a comprehensive portfolio of high-performance orthomode transducers (OMTs) covering frequencies up to 330 GHz. The orthomode transducer product series are available from WR-112 to WR-03 with square or circular waveguide common ports. Optimized, high performance designs are also available for popular SATCOM and telecommunication frequencies such as Ka-band (24.25-43.5 GHz), Q/V-band (37.5-52.4 GHz) and E-band (71-86 GHz).

SATCOM Feed Network And Components

Eravant offers a comprehensive portfolio of millimeter-wave components and integrated solutions optimized for next-generation satellite communication (SATCOM) ground stations and emerging 5G/6G infrastructure, covering Q/V-band (37.5–52.4 GHz) and E-band (71–86 GHz) frequency ranges. The product lineup includes high-performance orthomode transducers (OMTs), diplexers, polarizers, and weather-resistant dual circularly polarized feed systems designed for reliable outdoor deployment.

Slotted Waveguide Array Antenna

Eravant offers waveguide slotted array antennas for use in radar applications. The antennas typically have a bandwidth ranging from 4% up to 10% depending on the gain and can be customized to any center frequency. Radomes can be designed and integrated into the slotted array antennas for weather resistance. Custom designs can also be configured for space applications.

2 Watt Power Amplifiers for High Power System Integration

Eravant offers narrow and full band high power amplifiers for use in communications, instrumentation, radar, and high power system integration applications. The high power amplifier series covers the frequency range of 18 GHz to 110 GHz, and utilizes GaAs, GaN, and power combining technologies to achieve high power output.

Cassegrain Antennas for Satellite Communication

Eravant designs and manufactures standard and custom high performance cassegrain antennas for Q/V-Band satellite communication ground station applications. These antennas operate in the popular Q/V-band frequency spectrum with a downlink receiving (Rx) frequency range from 37.5 to 42.5 GHz and a uplink transmitting (Rx) frequency range from 47.2 to 52.4 GHz.

Compact Antenna Test Range

Eravant offers open bed CATR (Compact Antenna Test Range) and rolled edge reflectors for far-field OTA mmWave 5G and 6G antenna measurements. The systems and reflectors are available with Ø6” (150mm) and Ø12” (300mm) circular quiet zone sizes, and have been used to test antennas up to 330 GHz.

Direct Reading & Programmable Attenuators

Eravant has developed millimeterwave and Sub-THz “hybrid function” direct reading and programmable waveguide rotary vane attenuators for high level precision calibration, system power level control, and automated testing. The hybrid attenuator family covers a combined frequency range of 18 to 330 GHz in 13 distinct waveguide bands.

Waveguide Filters

Eravant offers a wide range of millimeterwave and sub-THz waveguide filters which covers many popular and emerging 5G and 6G telecommunication frequency bands, up to 330 GHz. All of Eravant’s filters are precision machined with tight tolerances and offer low insertion loss, high rejection, and for select models, steep rejection skirts.

Hermetic Coaxial Adapters

Eravant offers a series of hermetically sealed bulkhead type coaxial adapters for use as RF feedthroughs to enable testing of components in thermal vacuum chambers and cryogenic chambers where airtight vacuum seals are required.

High Power Amplifiers for Military & Defense

Engineered for mission-critical Ka-band platforms, Eravant power amplifier M/N: SBP-3233734045-KF28- E1-R delivers a 30 W output power with 40 dB power gain in CW mode. The amplifier is capable of operating in a pulsed mode, and covers 32 to 37 GHz frequency range. Housed in a 3⁄4 Short ATR chassis per ARINC 404, the module ships with a shock-isolated tray and front hooks for effortless integration into the vehicle.

High Power Rotary Joints

Eravant has developed a family of millimeterwave and Sub-THz rotary joints to support high-power system applications in the frequency range of 50 to 170 GHz. The rotary joint family consists of four mechanical configurations, “I’, “U”, “L” and “Reversed L” to provide convenience for system integrations and implementations.

Mini Faraday Isolators

Eravant offers miniature waveguide Faraday isolators for integration in subassemblies and test setups where space is limited. The mini isolator series covers a combined frequency range from 50 to 330 GHz. The design uses a saturated magnetic field configuration to achieve lower insertion loss and maintain high isolation while allowing for a much more compact package size compared to the traditional isolators.

mmWave & Sub-THz Radiometers

Standard full waveguide bandwidth W-Band and D-Band full power radiometric receivers are offered under the model numbers SSR-9333534040-10-M4 and SSR- 1446034540-06-M4 . They are direct detection based radiometric receivers that can be used to measure the average power of the noise coming from a physical object in frequency ranges of 75 to 110 GHz and 110 to 170 GHz.

Uni-Guide™ Patented Waveguide Connector

Branded as Uni-Guide™ waveguide connectors, the newly patented devices are compatible with existing coaxial interfaces. They greatly reduce the effort and cost of providing waveguide signal ports on hermetically sealed components. By using Uni-Guide™ waveguide connectors, component manufacturers can offer a wide range of waveguide sizes and orientations using a reduced number of package designs.

Waveguide to Coax Adapters

Eravant offers a series of full-band and broadband millimeterwave and sub-THz waveguide to coax adapters up to 173 GHz. Eravant’s waveguide to coax adapters are optimized to offer an efficient transition between the rectangular waveguide and the coaxial connector with low insertion loss and high return loss.

US 11,804,681 B1 — Waveguide to Coaxial Conductor Pin Connector

Granted: October 31, 2023
A low-loss, manufacturable waveguide-to-coaxial transition featuring an internal impedance-transforming structure to optimize mode conversion and reduce insertion loss in high-frequency applications.

USPTO: https://patft.uspto.gov/netacgi/nph-Parser?patentnumber=11804681

US 12,199,691 B2 — Waveguide Component for High Frequency Testing

Granted: January 14, 2025
A precision waveguide interface incorporating a recessed region and alignment protrusions to improve test repeatability, mechanical stability, and electrical performance during mmWave and sub-THz measurements.

USPTO: https://patft.uspto.gov/netacgi/nph-Parser?patentnumber=12199691

US 12,276,677 B1 — Waveguide Alignment System with Dual Plates

Granted: April 15, 2025
A dual-plate, multi-axis alignment system for mmWave test equipment, enabling fine mechanical alignment (x/y/z plus angular adjustments) between VNA extenders and DUTs, improving accuracy and repeatability in high-frequency testing.

USPTO: https://patft.uspto.gov/netacgi/nph-Parser?patentnumber=12276677
