WR-10 Waveguide to Coax Adapter

WR-10 Waveguide to 1 mm (F), End Launch, Thermal Vacuum Safe
SKU:SWC-101F-E1-V
Availability:1 Week ARO
Models SWC-101F-E1-V and SWC-101M-E1-V are end launch (180°) W-Band waveguide to coax adapters that cover the frequency range of 75 to 110 GHz. They are designed and manufactured for instrumentation grade quality and thermal vacuum compatibility, allowing for an efficient transition between the rectangular waveguide and 1.0 mm coax connector.
ECCN: EAR99
Login to View Pricing

Bulk Pricing

QuantityPrice
1 - 4$1,750.00
5 - 9$1,575.00
10 - 24$1,417.50

Bulk Pricing

Login to View Pricing

Technical Details

Minimum Frequency75 GHz
Maximum Frequency110 GHz
Insertion Loss1.20 dB
Return Loss15 dB
Power Handling10 W
Waveguide PortWR-10 Waveguide
Coax Type1 mm
Coax GenderFemale
ConfigurationEnd Launch (180°)
