WR-05 Waveguide Open

G-Band, Fixed
SKU:SWO-05-F1
Availability:IN STOCKPlease contact us if you need more units than what is available online.
SWO-05-F1 is a fixed waveguide open with a UG-387/U-M flange covering the frequency range from 140 to 220 GHz. The product consists of a waveguide short (model number SWS-VG-F1) and a ¼ ?g waveguide shim (model number SWI-05021-SB). The waveguide shim is 0.021" thick offering perfect open at the center frequency of 180 GHz when combined with the waveguide short. The product is manufactured with a precision machining process to ensure high quality and ruggedness. The open offers good reflection in the entire frequency range.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Quantity Price
1 - 24 $425.00
25 - 49 $382.50
50 - 99 $344.25

Bulk Availability

QuantityAvailability

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency140 GHz
Maximum Frequency220 GHz
Length0.021"
Waveguide FlangeUG-387/U-M Flange
Waveguide Short TypeFixed
