Bulkhead Coaxial Adapter

DC to 50 GHz, 2.4 mm (F) to 2.4 mm (F), Thermal Vacuum Safe
SKU:SCT-2F2F-UB-B-V
SCT-2F2F-UB-B-V is a 2.4 mm female to 2.4 mm female hermetically sealed bulkhead type coaxial adapter that covers the frequency range from DC to 50 GHz. The bulkhead adapter uses a glass bead and O-ring seal to provide a hermetically sealed RF interface between the vacuum and atmospheric environments. It is ideal for use as a coaxial RF feedthrough for testing in vacuum environments, such as a thermal vacuum chamber. It can also be used for other applications where an airtight vacuum seal is required. The bulkhead configuration gives mounting flexibility for a variety of mounting plates and flanges, such as ConFlat (CF) and KF vacuum flanges. Other configurations are available under different model numbers.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Quantity Price
1 - 9 $540.00
10 - 24 $486.00
25 - 49 $437.40

Bulk Availability

QuantityAvailability

Bulk Pricing

Login to view pricing

Technical Details

Minimum FrequencyDC
Maximum Frequency50 GHz
Insertion Loss-
Return Loss16 dB
Impedance50 Ohms
Connector GenderFemale to Female
Connector Series2.4 mm to 2.4 mm
ConfigurationPanel Mount (Bulkhead)
