2.92 MM Coaxial Lowpass Filter

DC to 26 GHz, 35 dB Rejection from 28 to 40 GHz
SKU:SCF-26328335-KFKM-L3
Availability:6 to 8 Weeks ARO
SCF-26328335-KFKM-L3 is a coaxial lowpass filter with a passband frequency from DC to 26 GHz. The typical passband insertion loss is 2.5 dB and the typical passband return loss is 11 dB. The rejection band is from 28 to 40 GHz with a typical rejection value of 35 dB. The RF ports of the filter are female and male 2.92mm (K) connectors. Other configurations, such as different connectors for input and output, are available under different model numbers.
ECCN: EAR99
Login to View Pricing

Bulk Pricing

QuantityPrice
1 - 4$1,200.00
5 - 9$1,080.00
10 - 24$972.00

Bulk Pricing

Login to View Pricing

Technical Details

Minimum Passband FrequencyDC
Maximum Passband Frequency26 GHz
Minimum Rejection Frequency28 GHz
Maximum Rejection Frequency40 GHz
Rejection35 dB
Insertion Loss2.5 dB
Return Loss11 dB
Impedance50 Ohms
Power Handling1 W
RF Ports2.92 mm (F) and 2.92 mm (M)
