SMA Coaxial Lowpass Filter

DC to 26 GHz, 35 dB Rejection from 28 to 40 GHz
SKU:SCF-26328335-SFSF-L3
Availability:6 to 8 Weeks ARO
SCF-26328335-SFSF-L3 is a coaxial lowpass filter to pass the frequency of DC to 26 GHz. The maximum insertion loss of the lowpass filter is 3.0 dB and passband ripple is ±0.5 dB. The rejection band is from 28 to 40 GHz and rejection value is 35 dB typical. The RF connectors of the filter are SMA(F) connectors. The passband return loss of the filter is 11 dB typical. Other configuration, such as different connectors for input and output are available under different model numbers.
ECCN: EAR99
Login to View Pricing

Bulk Pricing

QuantityPrice
1 - 4$1,200.00
5 - 9$1,080.00
10 - 24$972.00

Bulk Pricing

Login to View Pricing

Technical Details

Minimum Passband FrequencyDC
Maximum Passband Frequency26 GHz
Minimum Rejection Frequency28 GHz
Maximum Rejection Frequency40 GHz
Rejection35 dB
Insertion Loss2.5 dB
Return Loss11 dB
Impedance50 Ohms
Power Handling1 W
RF PortsSMA (F) and SMA (F)
