4 Hole Panel Mount Coaxial Adapter

DC to 110 GHz, 1.0 mm (F) to 1.0 mm (F), Thermal Vacuum Safe
SKU:SCT-1F1F-UB-PM4-V
Availability:4 to 6 Weeks ARO
SCT-1F1F-UB-PM4-V is a 1 mm female to 1 mm female panel mount coaxial adapter that covers the frequency range of DC to 110 GHz. The adapter is specifically designed and manufactured for testing in thermal vacuum environments. The adapter is made with low outgassing materials and includes a venting hole on the connector to allow unimpeded air flow during pressurization and depressurization cycles. The adapter is impedance matched at 50 Ohms and offers a typical insertion loss of 0.6 dB. Other configurations, such as panel mount adapters, are available under different model numbers.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Quantity Price
1 - 4 $1,100.00
5 - 9 $990.00
10 - 24 $891.00

Bulk Availability

QuantityAvailability

Bulk Pricing

Login to view pricing

Technical Details

Minimum FrequencyDC
Maximum Frequency110 GHz
Insertion Loss0.6 dB
Return Loss14 dB
Impedance50 Ohms
Connector 11.0 mm Female
Connector 21.0 mm Female
