W-Band Spot-Focusing Lens Antenna

SAQ-943205-10-S1 is a W-band, spot-focusing lens antenna that delivers a 10 dB spot size of 1.30" diameter at the focal length of 20.5". The antenna employs a low loss lens to offer excellent aperture efficiency in full W band frequency range of 75 to 110 GHz. The lens antenna is equipped with a standard WR-10 waveguide and UG-387/U-M anti-cocking flange as its input port. It supports linear polarized waveforms. For the intended application, it is recommended that customers purchase spot-focusing antennas (SAQ Series) in a pair of two (Qty. 2).
