W-Band Dual Channel, Doppler Sensor Module

94 GHz, +18 dBm Transmitting Power
SKU:SSM-94318-D1
SSM-94318-D1 is a W band Doppler sensor module that is designed and manufactured for medium range measurements of a moving target's speed and travel direction. The sensor module has an operating frequency of 94 GHz and takes a nominal bias of +8.0 VDC/750 mA. The sensor module is configured with a mechanically tuned oscillator, an isolator, a directional coupler, a circulator, a balanced I/Q mixer, and an oscillator voltage regulator. The directional coupler is used to sample the LO power to pump the mixer, and the circulator is used as a TX/RX diplexer. Various antennas can be integrated with the module to form sensor heads for many system applications.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Quantity Price
1 $15,415.00
2 $14,644.25
3 - 4 $13,912.04

Bulk Availability

QuantityAvailability

Bulk Pricing

Login to view pricing

Technical Details

RF Center Frequency94 GHz
Transmitting Power+18 dBm
Minimum IF FrequencyDC
Maximum IF Frequency3 GHz
Frequency Stability-6.0 MHz/°C
Power Stability0.04 dB/°C
DC Bias+8 VDC/400 mA
ChannelDual
