F-Band Compact Faraday Isolator, Limited Run

This is a Limited Run model, so inventory may not be restocked. Customers who anticipate long-term requirements should consider STF-08-91-M2 as an alternative solution. Read more about Limited Run Products here.

STF-08-91-C is a full band Faraday isolator that operates from 90 to 140 GHz. The Faraday isolator is constructed with a longitudinal, magnetized ferrite rod that causes a Faraday rotation of the incoming RF signal. The compact, robust package is ideal for system integration and testing applications and features a 90° twist between the input port and output port. The Faraday isolator offers 28 dB typical isolation and 2.5 dB nominal insertion loss with good flatness. The input and output ports are WR-08 waveguides with UG-387/U-M flanges. An in-line configuration is available under model number STF-08-S1-C.
