W-Band Subharmonically Pumped Mixer, Product Discontinued

90 to 100 GHz RF, 45 to 50 GHz LO, DC to 5.0 GHz IF, +15 dBm LO Power, WR-10 Waveguide
SKU:SFS-90311415-102FSF-N3
Availability:Contact Us for Quote
This product has been improved and is now listed as SFS-10-N1 and SFS-08-UEB. Read more about Limited Run Products here.

SFS-90311415-102FSF-N3 is a W-Band subharmonically pumped mixer. The mixer is designed with high performance GaAs Schottky diodes and accepts an LO frequency at half the RF frequency to cover the frequency range from 90 to 100 GHz. With a low LO frequency range of 45 to 50 GHz, this mixer is well suited for low cost W band system solutions. The mixer provides 15 dB conversion loss, 15 dB RF to LO isolation, and 30 dB LO to IF isolation.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Minimum RF Frequency90 GHz
Maximum RF Frequency100 GHz
Minimum LO Frequency45 GHz
Maximum LO Frequency50 GHz
Minimum IF FrequencyDC
Maximum IF Frequency5.0 GHz
LO Pumping Power+15 dBm
Conversion Loss15 dB
RF PortWR-10 Waveguide
