3rd Harmonic Mixer

85 to 100 GHz RF, 28.33 to 33.33 GHz LO, DC to 1.5 GHz IF, WR-10 Waveguide, W-Band
SKU:SFH-8531040313-10KFSF-N3
SFH-8531040313-10KFSF-N3 is a W-Band third harmonic mixer. The mixer is designed with high performance GaAs Schottky diodes to provide mixing at 3X LO frequency to cover the RF frequency range from 85 to 100 GHz. The low LO frequency makes this mixer well suited for low-cost W band system solutions with an LO frequency range of 28.33 to 33.33 GHz. The mixer provides typical 13dB conversion loss.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Quantity Price
1 - 2 $3,600.00
3 - 4 $3,420.00
5 - 9 $3,249.00

Bulk Availability

QuantityAvailability

Bulk Pricing

Login to view pricing

Technical Details

Minimum RF Frequency85 GHz
Maximum RF Frequency100 GHz
Minimum LO Frequency28.33 GHz
Maximum LO Frequency33.33 GHz
Minimum IF FrequencyDC
Maximum IF Frequency1.5 GHz
Conv. Loss13 dB
Harmonic Number3
RF PortWR-10 Waveguide
