Direct Reading Radar Target Simulator

83.5 GHz, WR-12, DC to 250 MHz I/Q Frequency, 30 dB Carrier Rejection, 20 dB Image Rejection
STR-843-12-D1 is a radar doppler simulator that operates at 83.5 GHz with a bandwidth of ±2.5 GHz and a WR-12 waveguide input/output. The simulator utilizes a single-sideband-modulator to modulate the incoming signal transmitted by the radar under test and sends back either a higher or lower band signal through a diplexer. The frequency-shifted signal is transmitted back to the radar under test as a Doppler signal. Target characteristics are adjusted by changing the I and Q channel frequency and phase. The routing attenuation is adjusted by the direct reading attenuator.
Login to view pricing

Bulk Pricing

Quantity Price
1 $8,500.00
2 $8,075.00
3 - 4 $7,671.25

Bulk Availability


Bulk Pricing

Login to view pricing

Technical Details

Frequency81 to 86 GHz
RF Bandwidth±2.5 GHz
Carrier Rejection30 dB
Image Rejection20 dB
I/Q Frequency MinimumDC
I/Q Frequency Maximum250 MHz
RF PortWR-12 Waveguide
I/Q PortsSMA (F)
