16-Way Coaxial Power Splitter

8 to 12.4 GHz, SMA (F)
SKU:SCS-0831233416-SFSF-162
Availability:4 to 6 Weeks ARO
SCS-0831233416-SFSF-162 is a coaxial 16-way power splitter with a typical insertion loss of 3.4 dB at each output port and a typical isolation of 16 dB across the frequency range of 8 to 12.4 GHz. The power splitter has a nominal power handling of 30 W (CW) and a typical amplitude unbalance of ±0.8 dB. The return loss for all ports is 11 dB typical. The RF connectors of the power splitter are female SMA connectors.
ECCN: EAR99
Login to View Pricing

Bulk Pricing

QuantityPrice
1 - 4$1,300.00
5 - 9$1,170.00
10 - 24$1,053.00

Bulk Pricing

Login to View Pricing

Technical Details

Minimum Frequency8 GHz
Maximum Frequency12.4 GHz
Ways16
Insertion Loss3.4 dB
Port Isolation16 dB
Return Loss11 dB
Impedance50 Ohms
RF ConnectorsSMA (F)
