SMA Coaxial Bandpass Filter

8.5 to 10.7 GHz, 70 dB Rejection
SCF-96222270-SFSF-B3 is a coaxial bandpass filter with a passband frequency of 8.5 to 10.7 GHz. The typical insertion loss of the bandpass filter is 1.0 dB and the passband ripple is ±0.4 dB. The rejection frequencies are DC to 8.2 GHz and 11 GHz or higher. The typical rejection is 70 dB and the typical passband return loss of the filter is 12 dB. The RF connectors of the the filter are SMA Female connectors. Other configurations are available under different model numbers.
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Minimum Passband Frequency8.5 GHz
Maximum Passband Frequency10.7 GHz
Low Side Rejection70 dB
High Side Rejection70 dB
Return Loss12 dB
Insertion Loss1.0 dB
Impedance50 Ohms
RF PortsSMA (F)
