E-Band Receiver

76 to 81 GHz, 1 to 6 GHz IF, +10 dBm LO Power
Availability:2 Weeks ARO
SSR-7930536018-12-S1 is an E-Band integrated receiver module. The receiver module has a typical noise figure of 6 dB and conversion gain of 18 dB in the frequency range of 76 to 81 GHz. The IF output frequency range is 1 to 6 GHz. The required LO power and frequency are +10 dBm and 12.5 GHz, respectively. The LO and IF port are both equipped with female SMA connectors and the RF port is with a WR-12 waveguide with UG-387/U flange.
Login to view pricing

Technical Details

Minimum RF Frequency76 GHz
Maximum RF Frequency81 GHz
Noise Figure6 dB
Gain18 dB
LO Frequency12.5 GHz
LO Input Power10 dBm
Bias Voltage8 VDC
RF PortWR-12 Waveguide
